Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine

  • Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine
  • Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine
  • Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine
  • Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine
  • Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine
  • Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine
  • Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine
Tempat asal PROVINSI SHANDONG, CINA
Nama merek SH
Sertifikasi ISO9001
Nomor model SHYM200, SHYM250, SHYM300, SHYM350, YM500, dll
Kuantitas min Order 1 set
Harga USD3,000-USD15,000/SET
Kemasan rincian pemuatan peti kemas dari beberapa gergaji sobek pisau
Waktu pengiriman Dalam 20 hari
Syarat-syarat pembayaran T/T atau L/C pada pandangan, Western Union
Menyediakan kemampuan 200 set/bulan

Contact me for free samples and coupons.

Ada apa:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Detail produk
Nama beberapa gergaji sobek Kondisi Baru
Maks. Menggergaji diameter log 500mm Tenaga motor utama 75kw x 2set
Diameter bilah bergigi karbida 650mm Motor makan 2.2KW
Diameter Spindel 100mm makanan kecepatan frekuensi disesuaikan
Berat 4100kg Ukuran keseluruhan 4900x 2750x1950mm
Cahaya Tinggi

Wood Sawmill Multiple Rip Saw

,

Ripsaw Wood Sawing Machine

,

Multiple Rip Saw 500mm
Tinggalkan pesan
Deskripsi Produk

Wood Sawmill Log Multiple Ripsaw, Carbide bergigi Multi Blade Rip Saw mesin gergaji kayu keras

Ripsaw multi bilah untuk Pemotongan Kayu Bulat

1.Potong batang kayu menjadi beberapa bagian per waktu.

2. Dengan konveyor makan pemusatan log

3. Kontrol otomatis

Model MALU150 MALU200 MALU240 MALU260
Menggergaji log diameter 20-150mm 60-200mm 80-240mm 100-260mm
Min panjang log menggergaji 600mm 600mm 600mm 600mm
Tenaga motor utama 18,5KW X 2 22KW X2 30KW X2 30kw, 37kw
Motor makan 1.5KW 1.5KW 1.5KW 1.5KW
Diameter mata gergaji 255mm 305mm 355mm 380mm
Berat 1570kg 1720kg 2200kg 2300kg
Model MALU285 MALU300 MALU330 MALU340
Menggergaji log diameter 130-285mm 150-300mm 150-330mm 150-340mm
Min panjang log menggergaji 600mm 600mm 600mm 600mm
Tenaga motor utama 30kw, 37kw 37KW X 2 37KW X 2 45kw, 55kw
Motor makan 2.2KW 2.2KW 2.2KW 2.2KW
Diameter mata gergaji 405mm 405mm 455mm 480mm
Berat 2350kg 2450kg 2550kg 2650kg
Model MALU360 SHYM400 MALU430 MALU480
Menggergaji log diameter 170-360mm 180-400mm 200-430mm 250-480mm
Min panjang log menggergaji 600mm 600mm 600mm 600mm
Tenaga motor utama 55KW X2 55KW X 2 75KW X 2 75KW X 2
Motor makan 2.2KW 2.2KW 2.2KW 2.2KW
Diameter mata gergaji 500mm 550mm 600mm 650mm
Berat 2680kg 3500kg 3880kg 4100kg

Perkataan:

Tenaga motor utama dapat diubah sesuai kebutuhan pelanggan;

Multi ripsaw dengan pengumpanan otomatis inverter

Metode pendinginan pisau: pusat poros menyemprotkan air untuk mendinginkan



Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine 0Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine 1Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine 2Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine 3

Ripsaw Multi Blades untuk Pemotongan Papan/Kayu



Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine 4

Notcher Palet Kayu

Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine 5

Mesin Pemaku Otomatis Pallet Kayu

Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine 6

Wood Sawmill Multiple Rip Saw 500mm Ripsaw Wood Sawing Machine 7
