Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw

Round Log Timber Multiple Multi Blade Rip Saw wWood Cutting Saw Machine
Round Log Timber Multiple Multi Blade Rip Saw wWood Cutting Saw Machine
Round Log Timber Multiple Multi Blade Rip Saw wWood Cutting Saw Machine Round Log Timber Multiple Multi Blade Rip Saw wWood Cutting Saw Machine Round Log Timber Multiple Multi Blade Rip Saw wWood Cutting Saw Machine Round Log Timber Multiple Multi Blade Rip Saw wWood Cutting Saw Machine Round Log Timber Multiple Multi Blade Rip Saw wWood Cutting Saw Machine Round Log Timber Multiple Multi Blade Rip Saw wWood Cutting Saw Machine
Informasi Dasar
Tempat asal: Provinsi Shandong, Cina
Nama merek: SH
Sertifikasi: ISO9001
Nomor model: MALU200,MALU250,MALUMA300,MALU350,MALU400,MALU450
Kuantitas min Order: 1 set
Harga: USD3000-USD15000/set
Kemasan rincian: palet kayu atau palet ekspor rangka besi
Waktu pengiriman: dalam 20 hari
Syarat-syarat pembayaran: T/T atau L/C saat dilihat, Western Union
Menyediakan kemampuan: 100 set/Bulan
Harga terbaik Hubungi sekarang
Informasi Detail
Nama: Gergaji Multi Rip Penggunaan: Pengerjaan kayu
Jenis: gergaji sobek Jenis makan: Makan otomatis
Penataan bilah: Atas/bawah Tegangan: 380V/3phase/50HZ atau sesuai kebutuhan pelanggan
Kekuatan: 22KW*2-75KW*2 <i>Max.</i> <b>Maks.</b> <i>sawing log diameter</i> <b>diameter batang gergaji</b>: 80MM-500MM
Jaminan: 12 bulan Layanan Pasca Penjualan: Insinyur tersedia untuk melayani mesin di luar negeri

Deskripsi Produk

Multi Blade Circular Sawmill Multi Rip Saw Mill untuk memotong log bulat atau kayu

Log Cutting Multiple Blade Ripsaw

Diameter maksimum potong log dapat mencapai 500mm ((20')



Spesifikasi:

Model
SHYM150
SHYM200
SHYM240
SHYM260
SHYM285
SHYM330
Diameter Log gergaji
20-150 mm
60-200mm
80-240mm
100-260mm
130-285 mm
150-330mm
MinSawing Log Length
600 mm
600 mm
600 mm
600 mm
600 mm
600 mm
Daya utama motor
18.5KW*2
22KW*2
30KW*2
30/37KW
30/37KW
37KW*2
Diameter Spindle
50 mm
50 mm
60 mm
60 mm
60 mm
70 mm
Diameter pisau gergaji
255mm
305mm
355mm
380mm
405mm


450 mm
Berat badan
1570KG
1720KG
2200KG
2300KG
2350KG
2550KG
Model
SHYM340
SHYM360
SHYM400
SHYM430
SHYM480
Diameter Log gergaji
150-340 mm
170-360 mm
180-400mm
200-430 mm
250-480 mm
Min Panjang Log gergaji
600 mm
600 mm
600 mm
600 mm
600 mm
Daya utama motor
45KW/55KW
55KW*2
55KW*2
75KW*2
75KW*2
Diameter Spindle
80 mm
80 mm
80 mm
100 mm
100 mm
Diameter pisau gergaji
480mm
500 mm
550 mm
600 mm
650 mm
Berat badan
2650KG
2680KG
3500KG
3880KG
4100KG

Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 0



Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 1

Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 2

Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 3



Papan Spindle Ganda Pemotongan Multi Blade Rip Saw

Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 4

Double Shaft Multi Blades Rip Saw untuk papan/kayu

Spesifikasi:

Model SH60-300 SH80-300 SH100-300 SH120-300 SH150-300
Max. Lebar gergaji 250-300 mm 250-300 mm 250-300 mm 250-300 mm 250-300 mm
Maks. ketebalan gergaji 60 mm 30-80mm 40-100mm 50-120mm 60-150 mm
Motor 18.5KW/22KW 22KW*2 22KW*2 22KW*2 30KW*2
Diameter pisau 150 mm 180 mm 210mm 230 mm 255mm
Diameter Spindle 50 mm 50 mm 50 mm 50 mm 50 mm
Berat badan 1190kg 1260kg 1420kg 1560kg 1620kg



Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 5Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 6

Double Shaft Multi Blades Rip Saw untuk papan/kayu

Spesifikasi:

Model SH100-400 SH120-400 SH160-400 SH200-400 SH250-400 SH270-400 SH290-400
Lebar gergaji 350-400 mm 350-400 mm 350-400 mm 350-400 mm 350-400 mm 350-400 mm 350-400 mm
Ketebalan gergaji 40-100mm 50-120mm 70-160mm 90-200mm 110-250mm 130-270mm 150-290mm
Motor 30kw*2 37kw*2 37/45kw 37/45kw 45kw*2 45/55kw 55KW*2
Diameter pisau gergaji 180 mm 230 mm 255mm 230 mm 280mm 280mm 380mm
Diameter Spindle 70 mm 70 mm 70 mm 80 mm 80 mm 80 mm 100 mm
Berat badan 2330kg 2450kg 2480kg 2550kg 2580kg 2620kg 2700kg
Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 7
Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 8
Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 9
Sistem pendingin air



Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 10

Panel kontrol

Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 11

Pengemasan

Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 12Kayu Log Bulat Multiple Multi Blade Rip Saw wMesin Pemotong Kayu Saw 13
