Mesin Pemotong Kayu Eucalyptus, Mesin Pembuat Serpihan Kayu, Mesin Penghancur Mesin Pemotong Kecil
| Place of Origin | Shandong Province, China |
|---|---|
| Nama merek | SH |
| Sertifikasi | ISO9001 |
| Model Number | SH216, SH218, etc |
| Minimum Order Quantity | 1 SET Wood Drum Chipper |
| Harga | USD11,000-72,000/SET |
| Packaging Details | container loading of wood chipper |
| Delivery Time | within 25 days for wood chipper |
| Payment Terms | Western Union, T/T |
| Supply Ability | 1500 Sets/Year of Wood Chipper |
Contact me for free samples and coupons.
Ada apa:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xDetail produk
| Name | Drum wood chipper | Application | Crush wood logs into wood chips |
|---|---|---|---|
| Keywords | Wood chipper | Feeding inlet size | 240x540mm, 310x680mm |
| Wood chip size | 20-30mm | Blade quantity | 2pcs |
| Motor power | 55KW, 110KW | Rotor diameter | 600mm, 800mm |
| Capacity | 5ton to 15ton/hour | Feeding conveyor length | 6meters |
Deskripsi Produk
Pemotong kayu gelondongan
Perkenalan:
1. Memproses diameter log: 50-300mm
2. Ukuran chip akhir: 20-40mm
3. Kapasitas produksi : 7-15 ton/jam
4. Kami juga dapat melakukan desain lini produksi sebagai kebutuhan pelanggan
Data teknis
| Model | SH216 | SH218 |
| Saluran Masuk Makan | 240*540mm | 310*680mm |
| Diameter Rotor | 650mm | 800mm |
| Kuantitas Pisau | 2 atau 3 | 2 atau 3 |
| Tenaga motor | 55KW | 110KW |
| Di Feed Conveyor | 6000mm | 6000mm |
| Konveyor Pakan Keluar | 10000mm | 10000mm |
| Kapasitas | 7-10T/JAM | 9-13T/JAM |
| Berat | 4070KG | 7500KG |
Produk-produk terkait:
| Mesin Pemotong Kayu Disk | |
| Spesifikasi | SHJP1600 |
| Ukuran saluran masuk makan | 450 * 450mm |
| Pisau No. | 6 foto |
| Tenaga motor utama | 185kw |
| Konveyor umpan horizontal | 8000mm |
| Slope outfeed conveyor | 10000mm |
| Ukuran pemotong kayu | 20-35mm |
| Jenis pemakaian | turun |
| Kapasitas produksi | 25-30t/jam |
Penghancur Komposit Kayu
| Model | SH2000-1000 | SH1300-600 | SH1400-600 | SH1600-600 | |
| Ukuran saluran masuk makan | 2000x1000mm | 1250x600mm | 1400x600mm | 1600x600mm | |
| Diameter rol pisau | 1400mm | 850mm | 850mm | 850mm | |
| Kecepatan rol pisau | 750RPM | 850RPM | 850RPM | 850RPM | |
| Kapasitas produksi | 70-100ton/jam | 12-15ton/jam | 18-20ton/jam | 25-30ton/jam | |
| 1 | Jumlah pisau palu YG8 | 86pcs | 20pcs | 24pcs | 28pcs |
| 2 | Jumlah pisau | 3grup/9tablet | 2grup/4tablet | 2grup/4tablet | 2grup/4tablet |
| Maks.Memproses diameter log | <800mm | 450mm | 450mm | 450mm | |
| Tenaga motor utama | 450kw | 160kw | 200kw | 250kw | |
| Ukuran pemotong kayu | 3-5cm | 2-4cm | 2-4cm | 2-4cm | |
| Kehidupan kerja pisau | 4000T-5000T | 4000T-6000T | 4000T-6000T | 4000T-6000T | |
|
Opsional :
|
|||||
Gambar jenis Listrik
Gambar tipe mesin Diesel
PENGHANCUR STUMP
1. Pengenalan:
- Mengolah Bahan Baku : akar/tunggul kayu, dahan, jerami, palet, dll.
- Makan diameter saluran masuk: 3600mm
- Diameter rotor: 800mm
- Kapasitas: 25-30 ton/jam
- jumlah pisau: 4 pcs dalam pisau H12
- Aplikasi: pembangkit listrik
2.Spesifikasi:
| Data teknis | Model SH3600-1600 |
| Ukuran poros pisau | 1600x850mm |
| Diameter rotor | 800mm |
| Kuantitas pisau | 4 |
| Tenaga motor utama | 185KW |
| Diameter saluran masuk makan | 3600mm |
| Konveyor umpan keluar | 12 meter |
| Kapasitas | 25-30Ton/Jam |
| Berat | 18000kg |
3.Foto:
