Mesin Gergaji Kayu Multi Blade 400mm Mesin Gergaji Rip Gergaji Kayu Lunak

Place of Origin	Shandong Province, China
Nama merek	SH
Sertifikasi	ISO9001
Model Number	SH80-300, SH120-300,SH250-400,SH290-400,SH150-400, etc
Minimum Order Quantity	1 SET Multi Rip Saw
Harga	US $3,300 - 12,000 / Set
Packaging Details	Iron frame packing or luo packings for multi rip saw
Delivery Time	within 20 days
Payment Terms	T/T or L/C at sight, Western Union
Supply Ability	1000sets/year

Contact me for free samples and coupons.

Ada apa:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Detail produk

Name	Multi rip saw	Power	18.5kw x 2sets to 55kw x 2sets
Feeding	Variable frequency speed adjustable auto feeding	Blade cooling	spindle center watering for blade cool
Max. sawing width	400mm	Max. sawing height	300mm
Blade arrangement	up/down	Main shaft diameter	50mm to 100mm
Blade quantity	5 to 10pcs or as customer needs	Carbide blade diameter	150mm to 380mm
Warranty	12 months	Application Wood	hardwood and softwood
After-sales service	video technical support, spare parts
Cahaya Tinggi	Mesin Gergaji Kayu Multi Blade 400mm , Mesin Gergaji Rip Gergaji 400mm , Mesin Gergaji Rip Gergaji Bundar

Tinggalkan pesan

Deskripsi Produk

Mesin Gergaji Kayu Multi Blade, Mesin Pemotong Kayu Gergaji Rip Saw Multi Blade

Panel Spindel Ganda Memotong Beberapa Pisau Rip Saw

1. Digunakan untuk Pemotongan Kayu / Panel / Papan

2.Maks.kedalaman pemotongan / ketebalan hingga 160mm

3.Maks.lebar pemotongan hingga 400mm

4. Daya motor besar, cocok untuk pemotongan kayu keras

5.Blades ditempatkan di atas/bawah abrod/spindle.

6. Kami menyajikan satu set cakram pada ketebalan pemotongan Anda

Spesifikasi:

Multi Blades Rip Saw- Untuk memotong panel kayu/papan

Model	SH60-300	SH80-300	SH100-300	SH120-300	SH150-300
Maks.Lebar gergaji	250-300mm	250-300mm	250-300mm	250-300mm	250-300mm
Maks.Ketebalan gergaji	60mm	30-80mm	40-100mm	50-120mm	60-150mm
Motor	18,5KW/22KW	22KW * 2	22KW * 2	22KW * 2	30KW * 2
Diameter Mata Gergaji	150MM	180mm	210mm	230mm	255mm
Diameter Spindel	50mm	50mm	50mm	50mm	50mm
Berat	1190kg	1260kg	1420kg	1560kg	1620kg

Mesin Gergaji Kayu Multi Blade 400mm Mesin Gergaji Rip Gergaji Kayu Lunak 0

Mesin Gergaji Kayu Multi Blade 400mm Mesin Gergaji Rip Gergaji Kayu Lunak 1

Panel Spindel Ganda Memotong Banyak Mata Gergaji Rip -Tipe Tugas Berat

Model	SH100-400	SH120-400	SH160-400	SH200-400	SH250-400	SH270-400	SH290-400
Lebar gergaji	350-400mm	350-400mm	350-400mm	350-400mm	350-400mm	350-400mm	350-400mm
Ketebalan gergaji	40-100mm	50-120mm	70-160mm	90-200mm	110-250mm	130-270mm	150-290mm
Motor	30kw * 2	37kw*2	37/45kw	37/45kw	45kw*2	45/55kw	55KW * 2
Diameter Mata Gergaji	180MM	230mm	255mm	230mm	280mm	280mm	380mm
Diameter Spindel	70mm	70mm	70mm	80mm	80mm	80mm	100mm
Berat	2330kg	2450kg	2480kg	2550kg	2580kg	2620kg	2700kg

Mesin Gergaji Kayu Multi Blade 400mm Mesin Gergaji Rip Gergaji Kayu Lunak 2

Gergaji Rip Pemotongan Kayu Multi Blade

Data teknis

Model	MALU150	MALU200	MALU240	MALU260	MALU285	MALU330
Diameter Kayu Gergaji	20-150mm	60-200mm	80-240mm	100-260mm	130-285mm	150-330mm
Panjang Log Min Sawing	600mm	600mm	600mm	600mm	600mm	600mm
Tenaga Motor Utama	18,5KW*2	22KW * 2	30KW * 2	30/37KW	30/37KW	37KW * 2
Diameter Spindel	50mm	50mm	60mm	60mm	60mm	70mm
Diameter Mata Gergaji	255mm	305mm	355mm	380mm	405mm	450mm
Berat	1570KG	1720KG	2200KG	2300KG	2350KG	2550KG

Model	MALU340	MALU360	SHYM400	MALU430	MALU480
Diameter Kayu Gergaji	150-340mm	170-360mm	180-400mm	200-430mm	250-480mm
Panjang Log Penggergajian Min	600mm	600mm	600mm	600mm	600mm
Tenaga Motor Utama	45KW/55KW	55KW * 2	55KW * 2	55KW * 2	55KW * 2
Diameter Spindel	80mm	80mm	80mm	100mm	100mm
Diameter Mata Gergaji	480mm	500mm	550mm	600mm	650mm
Berat	2650KG	2680KG	3500KG	3880KG	4100KG

Mesin Gergaji Kayu Multi Blade 400mm Mesin Gergaji Rip Gergaji Kayu Lunak 4

Mesin Gergaji Kayu Multi Blade 400mm Mesin Gergaji Rip Gergaji Kayu Lunak 5

Lini Produksi Gergaji Multi Rip Kayu Otomatis

Lini produksi akan meningkatkan kecepatan pemrosesan kayu dan hanya membutuhkan 3-5 pekerja untuk keuntungan ekonomi yang lebih besar.

Diameter log gergaji maks adalah 350-450mm.

Kami dapat merancang lini produksi sesuai dengan diameternyalog Anda.
